Eco-friendly Design
Smart Scanning
Speedy RSPF
10.1-inch Full-flat Touchscreen
Unified Cloud Connection
Solid Security
Link Mobile Devices
All the Needed Finishing Options
Online Firmware Updates
| GENERAL (-) | |
| Type | Digital Full Colour Multifunctional System |
| Engine speed (colour & B/W) | A4: Max. 45 ppm A3: Max. 23 ppm SRA3: Max. 21 ppm |
| Control panel display | 10.1-inch colour LCD touchscreen |
| Paper Size | Max. SRA3 (12" × 18") Min. A6 |
| Paper capacity(80 g/m²) | Standard: 650 sheets (550-sheet tray + 100-sheet bypass tray) Maximum: 6,300 sheets (with optional trays) |
| Paper weight | Tray: 60 – 300 g/m² Bypass tray: 52 – 300 g/m² |
| Warm-up time | Approx. 27 seconds |
| Memory | Standard: 5 GB (copy / print shared) Storage: 128 GB SSD Optional: 512 GB SSD |
| Power requeirements | Rated local AC voltage ±10%, 50 / 60 Hz |
| Power Consumption | Max. 1.84 kW (220 – 240 V) |
| Dimensions(W×D×H) including document cover | 608 × 653 × 829 mm |
| Weight(approx.) | 78 kg |
| COPIER (-) | |
| Original size | Max. A3 |
| First copy time | Colour: 7.6 sec B/W: 5.6 sec |
| Resolution | Scan: 600 × 600 dpi Print: 600 × 600 dpi (up to 9,600 equivalent × 600 dpi) |
| Continuous copy | Max. 9,999 copies |
| Gradation | 256 levels |
| Zoom range | 25% – 400% (1% increments) |
| Preset copy rations | Metric: 10 ratios (5R / 5E) Inch: 8 ratios (4R / 4E) |
| NETWORK PRINTER (-) | |
| Resolution | 1,200 × 1,200 dpi 600 × 600 dpi 9,600 (equivalent) × 600 dpi |
| Interface | USB 2.0 (Host) USB 3.0 (Host) 10Base-T / 100Base-TX / 1000Base-T |
| Network protocols | TCP/IP (IPv4 / IPv6) |
| Printing protocols | LPD Raw TCP (Port 9100) IPP FTP SMB WSD |
| PDL | PCL 6 PostScript 3 (optional) |
| Supported OS | Windows macOS (optional) |
| Available fonts | 80 fonts (PCL) 136 fonts (PostScript) |
| COLOUR SCANNER (-) | |
| Resolution | 600 × 600 dpi |
| File formats | TIFF PDF PDF/A Encrypted PDF JPEG XPS |
| Protocols | TCP/IP SMTP FTP SMB WebDAV |
| Scanner utility | harpdesk Sharpdesk Mobile |
| Network Scanner (-) | |
| Scan method | Push scan / Pull scan |
| Scan speed | Up to 80 opm (one-sided) |
| Resolution | 600 × 600 dpi |
| Scanner utility | Sharpdesk Sharpdesk Mobile |
| Scan destinations | Email Desktop FTP server Network folder (SMB) USB |
| File formats | TIFF PDF PDF/A Encrypted PDF JPEG XPS |
| Document Filing (-) | |
| Document filing capacity | Approx. 20,000 pages |
| Stored jobs | Up to 1,000 jobs |
| Storage folders | Main folder Custom folders Confidential folders |
| Confidential storage | Yes |
| B/W Facsimile (-) | |
| Compression method | MH / MR / MMR / JBIG |
| Communication protocol | Super G3 |
| Transmission time | Approx. 2 seconds / page |
| Modem speed | 33.6 kbps |
| Transmission resolution | Standard / Fine / Super Fine |
| Recording size | A3 – A5 |
| Memory | Standard: 1 GB |
| Grey scale levels | 256 levels |
