Sharp Copier/MFP
- 100-sheet RSPF and stackless duplex module
- Space-efficient inner finisher and punch module
- Handles paper up to 300 g/m2 thick and extra-long paper up to 1,200 mm
- USB port*1 allows easy print from*2/scan to USB memory
- Efficient PDF*2/TIFF/JPEG direct printing
- 2nd-generation Mycrostoner-HG (High Grade) faithfully reproduces fine lines and halftone colours
- Auto Colour Mode and Auto Colour Selection f
All the Document Essentials Plus Colour — Now Is the Time to Upgrade



Superb Image Quality
- Selectable Printer Languages
- Enhanced Scanning and Copying
- Improved Imaging System

Productivity
- Super-Efficient Output
- RSPF and Stackless Duplex Module
- Job-Build for Large-Volume Scanning
- Versatile Paper Handling, In-Line Finishing Options
- Direct Printing

Other Key Features
- User-Friendly Control Panel
- Multi-Layered Security
- Information Sharing
- Outstanding Eco Technology
- Expandability

GENERAL (-) | |
Type | Desktop |
Engine speed (colour & B/W) | A4: 25 ppm, 8 1/2" x 11": 24 ppm, A3 (11" x 17"): 11 ppm |
Control panel display | 7.0-inch colour LCD touchscreen |
Paper Size | Max. A3 wide (12" x 18"), min. A5 (5 1/2" x 8 1/2") |
Paper capacity(80 g/m²) | Standard: 600 sheets (500-sheet trays × 2 and 100-sheet multi-bypass tray) Maximum: 2,100 sheets |
Paper weight | Tray: 60 g/m² to 220 g/m² (16 lbs bond to 80 lbs cover) Multi-bypass tray: 55 g/m² to 300 g/m² (13 lbs bond to 110 lbs cover) |
Warm-up time | 45 sec. |
Memory | Standard: 2GB (copy/print shared), Option: 1GB, 250GB HDD |
Power requeirements | Rated local AC voltage JÀ10%, 50/60 Hz |
Power Consumption | Max.1.84 kW (220 to 240V) |
Dimensions(W×D×H) including document cover | 583 x 617 x 834 mm (22 61/64" x 24 19/64" x 32 27/32") |
Weight(approx.) | 73 kg (161.0 lbs) |
COPIER (-) | |
Original size | Max. A3 (11" x 17") |
First copy time | Full colour: 10.0sec. B/W: 7.4 sec |
Resolution | Max. 999 copies |
Continuous copy | Scan (colour): 600 x 600 dpi, Scan (B/W): 600 x 600 dpi, 600 x 400 dpi, 600 x 300 dpi, Print: 600 x 600 dpi, 9,600 x 600 dpi |
Gradation | Equivalent to 256 levels |
Zoom range | 25% to 400% (25% to 200% using RSPF) in 1% increments |
Preset copy rations | Metric: 10 ratios (5R/5E), inch: 8 ratios (4R/4E) |
NETWORK PRINTER (-) | |
Resolution | 600 x 600 dpi, 9,600 (equivalent) x 600 dpi |
Interface | USB 2.0, 10Base-T/100Base-TX/1000Base-T |
Network protocols | TCP/IP (IPv4, IPv6), IPX/SPX (NetWare), EtherTalk (AppleTalk) |
Printing protocols | LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP, FTP for downloading print files, EtherTalk printing, IPP |
PDL | Standard: Sharp Advanced Printing Language-c, PCL 6 emulation |
Supported OS | Windows Server® 2008, 2008 R2, 2012, 2012 R2, 2016, Window Vista®, Windows® 7/8.1/10, MAC OS 10.4 to 10.13 |
Available fonts | 80 fonts for PCL, 136 fonts for Adobe® PostScript® 3™ |
Network Scanner (-) | |
Scan method | Push scan (via control panel), Pull scan (TWAIN-compliant application) |
Scan speed | [Colour& B/W]Max. 31 originals/min. |
Resolution | Push scan: 100, 150, 200, 300, 400, 600 dpi,Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi,50 dpi to 9,600 dpi via user setting |
File formats | TIFF, PDF, PDF/A, encrypted PDF, JPEG, XPS |
Scanner utility | Sharpdesk |
Scan destinations | Scan to e-mail/FTP server/network folder (SMB)/USB drive |
Document Filing (-) | |
Document filing capacity | Main and custom folders: 20,000 pages or 3,000 files, Quick file folder: 10,000 pages or 1,000 files |
Stored jobs | Copy, print, scan, fax transmission |
Storage folders | Quick file folder, main folder, custom folder (max. 1,000 folders) |
Confidential storage | Password protection |
B/W Facsimile (-) | |
Compression method | MH/MR/MMR/JBIG |
Communication protocol | Super G3/G3 |
Transmission time | Less than 3 seconds |
Modem speed | 33,600 bps to 2,400 bps with automatic fallback |
Transmission resolution | From Standard (203.2 x 97.8 dpi) to Ultra Fine (406.4 x 391 dpi) |
Recording size | A3 to A5 (11" x 17" to 5 1/2" x 8 1/2") |
Memory | 512MB, max. 1GB |
Grey scale levels | Equivalent to 256 levels |
